1. Remove all the contents from inside of the vacuum cleaner container.
2. Turn the container upside down and insert the feet with casters into the slots and apply
pressure until they click into place. Secure them with supplied screws.
3. Your vacuum cleaner comes ready for dry vacuum cleaning with the cartridge filter pre-installed. If the cartridge filter is not installed, refer to page 10.
4. Optionally, for improved dust filtration and hygienic disposal, fully fit the dust bag flange onto
the inlet stub.

NOTE: The dust bag is for dry pick-up only.

5. For wet vacuum cleaning, replace the cartridge filter with the foam filter supplied. Do not use a dust bag when wet vacuuming. If the foam filter is not installed.
6. Secure the power head back onto the container using the latches.
7. Insert the locking end of the hose into the suction port of the container and turn clockwise to lock into place.
8. The included accessories lock together to prevent them from detaching during use. Connect the desired accessories and/or extension wands onto the end of the hose by aligning the tabs and push together until they lock into place. To remove the accessory, press down on the locking tab and slide it off.

General Maintenance

1) Keep all safety devices, air vents and the motor housing free of dirt and dust. Use a soft, dry brush to clean the equipment regularly.
2) Clear all dirt or debris from the collection tank after each use. Allow to dry before replacing the power head. Do not use cleaning agents or solvents; these may damage the appliance.
3) Check the hose, attachments, and power cord to verify that they have not been damaged or any debris is trapped and blocking airflow.

Cleaning Cartridge Filter

Remove the filter and clean by gently tapping or brushing off dirt. For optimal performance it is recommended to replace the old filter with a new filter regularly.

Cleaning Foam Filter

Remove the foam filter and use a mild soap and water solution to wash and rinse with clean water. Allow the filter to air dry completely before storing or re-installing.
