ASSEMBLY

1. Insert the handle into the top of the main body until you hear a “click”.

To remove: Insert a screwdriver into the hole located on the back of the main body and lift the handle
at the same time.

2. Align the accessory holder with the slot of the charging base. Slide down until it secures into
place. The brushroll and cleaning tool can be stored in the accessory holder.

Charging

WARNING: Before charging make sure the hard floor cleaner is turned OFF. Ensure the
dirty water tank is empty.

1. Insert the charging adapter into the charging port located on the back of the charging base.
2. Place the hard floor cleaner onto the charging base.
3. Plug the charging adapter into a power outlet.

NOTE: When the hard floor cleaner begins to charge, the battery status indicator will turn on.

NOTE: When the hard floor cleaner has been fully charged (100%), the display screen turns off.
Disconnect the charging adapter from the storage base, then unplug it from the outlet.

NOTE: Make sure the hard floor cleaner is fully charged before using for the first time.

Always follow all safety precautions when performing maintenance to the hard floor cleaner.

WARNING: To reduce the risk of an electric shock, ensure the hard floor cleaner is turned off before performing any maintenance.

1. Brushroll Self-Cleaning

WARNING
• Ensure the charging base is plugged in.
• Before brushroll self-cleaning, clean the dirty water tank and ensure the water level in the clean water tank is above 40%.

1) Place the hard floor cleaner onto the charging base. The hard floor cleaner will begin to charge.
2) Press the self-cleaning button on the handle to activate self-cleaning mode.

NOTE: The brushroll self-cleaning mode lasts approximately 2 minutes. If needed, repeat the self-cleaning process.

NOTE: To stop the brushroll self-cleaning mode, press the self-cleaning button.

3) When the hard floor cleaner completes the self-cleaning mode, the cleaner will resume
charging.
4) Empty and clean the dirty water tank.

2. Cleaning The Brushroll Cover

1) To remove the brushroll cover, hold the brushroll cover and press the brushroll cover release
button. Pull up and away.
2) Rinse the brushroll cover with clean water.
3) Place the brushroll cover back onto the floor head until you hear a “click”.

3. Cleaning & Removing The Brushroll

1) Remove the brushroll cover from the floor head.
2) Remove the brushroll by pressing the brushroll tab and pulling upward.
3) Remove the brushroll cleaning tool from the handle of the 2-in-1 cleaning tool. Using the brushroll cleaning tool, remove any hair and debris wrapped around the roller. After use, put the brushroll cleaning tool back into the handle.
4) Wash the brushroll with clean water. A mild detergent can also be used.
5) Allow to air dry completely before storing or reinstalling.
6) Reinstall the brushroll into the floor head until you hear a “click”.
7) Place the brushroll cover back onto the floor head until you hear a “click”.

4. Removing a Blockage

1) Remove the dirty water tank.
Remove the brushroll.
2) Use the 2-in-1 cleaning tool to clear the debris channels of hair, dirt and debris.
Remove the hair and debris wrapped around the roller. Clean regularly to avoid any build up.

NOTE: Do not use scissors or other sharp objects to remove blockages.

5. Hard Floor Cleaner Storage

1) Store your hard floor cleaner in a protected, dry area.
2) Since the hard floor cleaner uses water, it must not be stored where there is danger of freezing. Freezing will damage internal components and may void the warranty.

WARNING: To reduce the risk of fire, electric shock or injury, turn OFF the appliance and disconnect plug from the electrical outlet before performing maintenance or troubleshooting on
the charging base.
