Blower Assembly

1. Align the protrusions on the air duct with the grooves on the blower tube. Insert the blower tube onto the air duct and turn it to lock into place. Ensure it is secured. To remove the blower tube, reverse the installation steps.

2. Align the protrusions on the blower tube with the grooves on the concentrator nozzle. Insert the concentrator nozzle onto the blower tube and turn it to lock into place.

Installing the Battery Pack

1. Align the support rails located on the battery chamber with the guide rails on the battery pack.

2. Slide the battery pack fully towards the handle until it clicks into place. Ensure it is secured.

General Maintenance

1. Keep all safety devices, air vents and the motor housing free of dirt and dust. Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use clean, dry cloths to remove dirt, dust, oil, grease, etc.

2. Remove any buildup of grass and leaves on or around the motor cover. Wipe the blower clean with a dry cloth occasionally. Do not use water as this may damage any electrical components.

3. To store the blower, remove the battery from the blower. Store the blower in a dry place out of the reach of children.

4. Always allow the blower to cool down before storing.

5. The storage hook on the bottom of the blower is convenient for hanging it with a nail or screw on the wall.

Battery and Charger Maintenance

1. Keep the battery and charger clean and clear of debris. Do not allow foreign material into the recessed cavity or on the contacts. Wipe with a dry cloth. Do not use solvents, water, or place in wet conditions.

2. Always unplug the charger when there is no battery pack in it.

3. Check that the charger and battery contacts have not been shorted by debris or foreign material. Always store away from metal objects which could create a connection with the terminals.

4. Always remove the battery when storing the blower and keep in a cool dry place out of direct sunlight.

5. Store the battery only within a temperature range between 0°C and 25°C and do not subject or store the battery pack to direct sunlight.

6. It is recommended to store the lithium-ion battery pack in a 30%-50% charged condition.

7. It is recommended to fully charge the lithium-ion battery pack after every six months of storage.
