1. Attach the lower hose storage clip to the carpet cleaner as shown and secure it with the provided screw.

NOTE: Tighten the screw with a Phillips head screwdriver. Ensure that the screw is secured.

2. Attach the upper hose storage clip to the carpet cleaner as shown and secure it with the provided screw.

NOTE: Tighten the screw with a Phillips head screwdriver. Ensure that the screw is secured

3. Select the preferred attachment and slide it onto the end of the suction hose until it clicks into place.

To remove: Press the tool release button and pull away the the attachment.

NOTE: When not in use, wrap the suction hose into the lower hose storage clip. Click the end of the hose, with the tool attached, into the upper hose storage clip.

4. Lift the battery compartment cover and insert the battery into the battery compartment until you hear a ‘click’. Make sure the battery firmly secures into place and put down the cover.

To remove: Press the battery release button on the battery, grasp the battery firmly and pull it out of battery compartment.

Cleaning Exterior

1) Turn off and disconnect the battery from the carpet cleaner.
2) To clean exterior, or to reduce static electricity and dust build-up, wipe outer surface with a clean, soft cloth that has been dipped in a solution of mild liquid detergent and water, then wring dry. Wipe dry after cleaning.

Cleaning Tools

It is recommended to clean tools with water after each use.
1) Press the tool release button to remove the attachment from the suction hose.
2) Pry open the cover release tab on the nozzle to remove the cover.
3) Rinse thoroughly with clean water. Allow the parts to dry before reinstalling.
4) Reinstall the nozzle cover back into place until a click is heard.


Hose Cleaning Tool

1) Remove the clean water tank and fill with warm water (Max 40°C).
2) Attach the hose cleaning tool to the suction hose. Ensure any tools or attachments are removed.
3) Make sure both the clean water and dirty water tanks are secured on the unit.
4) Press the power button to turn the carpet cleaner on and hold the spray trigger for 30 seconds. The clean water will rush through the suction hose, effectively cleaning and removing any trapped dirt and debris in the hose which may build up over time. Repeat as needed. Let the machine run for 5-10 seconds before turning off.
5) Turn off and disconnect the battery from the carpet cleaner.

Cleaning the Filter Grill

1) Remove the dirty water tank from the side of the unit.
2) Remove any dirt and debris from the filter grill as shown.

Removing A Hose Blockage

1) Use a Phillips screw driver to unscrew the hose and remove it from the spot cleaner. Do not pull the hose excessively.
2) Check and remove any blockages from the hose inlet.
3) Ensure the sealing ring is positioned on the hose properly. Reattach the hose onto the spot cleaner and tighten the screw.

NOTE: Do not use scissors or other sharp objects to remove blockages from the hose as these may damage the hose.

Storage

1) Disconnect the battery before storage.
2) Place the suction hose and attachments in their storage positions.
3) Empty the clean water tank (if necessary). Rinse it out before placing back on the unit. Open the clean water tank cover to allow it to air dry.
4) Empty the dirty water tank then rinse, clean and dry before placing back on the unit.
5) Store the carpet cleaner in a dry and cool indoor area.
